Engine
| Mootori tüüp | Vedelikjahutusega, 4-taktiline paralleelasetusega kahesilindriline mootor |
|---|---|
| Surveaste | 11.3:1 |
| Klapisüsteem | DOHC, 8 valves |
| Läbimõõt x käik | 70.0 x 58.6 mm |
| Kubatuur | 451 cm³ |
| Kütusesüsteem | Fuel injection: 32 mm x 2 |
| Õlitus | Sundõlitus, õlivann |
| Käivitussüsteem | Elektriline |
| Süütesüsteem | Digitaalne |
Performance & Transmission
| Maksimaalne võimsus | 33.4 kW {45 PS} / 9,000 rpm |
|---|---|
| Maksimaalne pöördemoment | 42.6 N•m {4.3 kgf•m} / 6,000 rpm |
| CO2 emissioon | 89.0 g/km |
| Kütusekulu | 3.8 l/100km |
| Ülekanne | 6 käiku |
| Sidur | Märg mitme kettaga |
| Esmane ülekandearv | 2.029 (69/34) |
| 1. käigu ülekandearv | 2.929 (41/14) |
| 2. käigu ülekandearv | 2.056 (37/18) |
| 3. käigu ülekandearv | 1.619 (34/21) |
| 4. käigu ülekandearv | 1.333 (32/24) |
| 5. käigu ülekandearv | 1.154 (30/26) |
| 6. käigu ülekandearv | 1.037 (28/27) |
| Lõppülekanne | Kinnine kett |
| Lõplik ülekandearv | 3.071 (43/14) |
Frame & Dimensions
| Raami tüüp | Võrestik, kõrge jäikusega teras |
|---|---|
| Rake | 24.3 ° |
| Kaugus pöördekeskmest | 92 mm |
| Amordikäik, esimene | 120 mm |
| Amordikäik, tagumine | 130 mm |
| Rehv ees | 110/70R17 M/C 54H |
| Rehv taga | 150/60 R17 M/C 66H |
| P x L x K | 1,995 x 800 x 1,055 mm |
| Pöördenurk V/P | 35° / 35° |
| Teljevahe | 1,375 mm |
| Kõrgus maapinnast | 145 mm |
| Kütusepaagi maht | 14.0 liitrit |
| Istme kõrgus | 785 mm |
| Tühimass* | 167 kg |
| | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
| Estimated dry weight** | 153 kg |
| | **Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). |
Brakes & Suspension
| Pidurid ees | Üks poolpinnaline ketas |
|---|---|
| Esipiduri läbimõõt | Ø 310 mm |
| Esimese pidurisadula tüüp | Tasakaalustatud käivitamine kahe kolbiga |
| Pidurid taga | Üksik ketas |
| Tagapiduri läbimõõt | Ø 220 mm |
| Tagumise pidurisadula tüüp | Kahekolbilised |
| Vedrustus ees | - |
| Esivedrustuse diameeter | Ø 41 mm |
| Vedrustus taga | Alahoovaga Uni-Trak gaasiamortisaatori ja reguleeritava eelpingsusega |
Lisavarustus
Help protect your motorcycle from tip-over damage.
- High-density black ABS plastic Frame Sliders feature the Kawasaki logo and are mounted with factory-designed metal brackets
- Includes required brackets, hardware and installation instructions
- Frame Sliders help protect your motorcycle but will not prevent all types of damage
Give your Kawasaki bike a more sporty look and sound with this Akrapovič slip-on system. This lightweight slip-on system offers great performance. The combination of racing materials like titanium for the muffler outer sleeve and carbon fiber end cap give this exhaust system a racing touch. The heatshield is included.
This homologated exhaust system is compliant with Euro5+ regulations (emissions and noise) and has EC type-approval.
Semi rigid Nylon tank bag specially designed for the fuel tank shape.
Black/Grey tank bag with reflective piping and Kawasaki logo.
Pocket with transparent plastic window at top of tank bag with hole for earphone.
Inside has partitions to prevent goods moving around.
Including shoulder belt and rain cover with transparent window.
L350mm, W223mm,H150mm
Load Weight Max 2kg
Load Capacity approximate 4 Litre.
A matching bracket is required for fitment.
An essential tool for motorcycle enthusiasts and mechanics alike. Designed to provide stability and convenience, this paddock stand allows easy access to the wheels, suspension, and other components.
This premium rear bike stand can be disassembled, making transportation a lot easier. The compact bike stand comes in a shop worthy carrying case with a built-in carrying handle. The stand is made of premium steel and has a green and black finish. The Kawasaki logo is laser cut in steel.
Optional are the forks to suit your preference;
- The Y-forks are to be used in combination with bobbins. (163JAY0021)
- The L-forks can be used to support the rear swing arms. (163JAY0022)
Whether you want to park your bike in a pitbox or in your garage, let your precious machine rest in style on this Kawasaki Garage Mat. The mat meets new FIM environmental codes and offers a high level of absorption and dust-control features.
- Size 100cm x 200cm
- Pile weight ± 300 gr/m²,
- Total height ± 5 mm,
- 30°C washable (no tumble-dry)
